Introduction to strip connectors

The strip connector is a classification of rectangular connectors. The basic structure is bar type, the contact is arranged in a single row, and the connector has a bar type mating surface.

Function of strip connector

Strip connector is a kind of component that electronic engineers often contact. Its role is very simple. It builds a bridge of communication between blocked or isolated circuits in the circuit, so that the current can flow and the circuit can achieve the intended function.

Advantages of strip connectors

1. Improve production process

The strip connector simplifies the assembly process of electronic products. It also simplifies the batch production process.

2. Easy to maintain

If an electronic component fails, the failed component can be quickly replaced when a strip connector is installed.

3. Easy to upgrade

With the progress of technology, the components can be updated when the strip connector is installed, and the old components can be replaced by new and more complete components.

4. Improve design flexibility

The use of strip connectors gives engineers greater flexibility in designing and integrating new products, as well as in composing systems with components.

Electrical characteristics of strip connectors

1. The insulation resistance is an index to measure the insulation performance between the contacts of electrical connectors and between the contacts and the shell, and its order of magnitude ranges from hundreds of megohms to thousands of megohms.

2. The electrical connector with high contact resistance shall have low and stable contact resistance. The contact resistance of the connector varies from a few milliohms to tens of milliohms.

3. Dielectric strength, or withstand voltage and dielectric withstand voltage, is the ability to withstand rated test voltage between connector contacts or between contacts and shell.

4. Other electrical properties.
